Intensity Modulator

AM20-Overview
20GHz Analog Intensity Modulator, Lithium Niobate Fiber Modulatorwith the Features of Titanium In-Diffused Waveguides, X-cut LiNbO3 2nd Harmonic Suppression, 45dB, Tpy. Low Drive Voltage Compatible with Commercially Available Drivers Low Optical Insertion Loss, 4.5dB, Typ. C and L Operation Wavelength Range Smooth Frequency Response up to 20 GHz Integrated Photodiode […]

20GHz Intensity Modulator for Analog Applications, OCLARO AM-20

FTM7939EK
40Gbps Intensity Modulator, Fujitsu FTM7939EK, Lithium Niobate Fiber Modulator 40Gbps Intensity Modulator with the Features of • Low Drive Voltage, RF VπVoltage 3.5V@43GBaud, Typ. • 40Gbps Mach-Zehnder Modulator Using Ti-diffused LiNbO3 Waveguide Technology • Separated DC Bias Port for Each Mach-Zehnder Interferometer • Low Insertion Loss, ≤5dB Typ. • Separated […]

40Gbps Intensity Modulator, Fujitsu FTM7939EK

FTM7938-1 - Cut
40Gbps Intensity Modulator, Fujitsu FTM7938EZ, Lithium Niobate Fiber Modulator This optical modulator is a Ti:LiNbO3 Single Drive Mach-Zehnder modulator with modulation speed of up to 43 Gb/s. This optical modulator integrates a monitor PD chip and coupler function for automatic bias control (ABC) for the compensation system of DC-drift and […]

40Gbps Intensity Modulator, Fujitsu FTM7938EZ

OverView
40Gbps Intensity Modulator, Fujitsu FTM7937EZ, Lithium Niobate Fiber Modulator This optical modulator is a Ti:LiNbO3 Dual Drive Mach-Zehnder modulator with modulation speed of up to 43 Gb/s. This optical modulator integrates a monitor PD chip and coupler function for automatic bias control (ABC) for the compensation system of DC-drift and […]

40Gbps Intensity Modulator, Fujitsu FTM7937EZ

FTM7920FBA
20Gbps Intensity Modulator, Fujitsu FTM7920FBA, Lithium Niobate Fiber Modulator 20Gbps Intensity Modulator with the Features of • Low Drive Voltage, RF VπVoltage 5V@12Gps, 8V@22GHz, Typ. • Mach-Zehnder Modulator for RZ Pulse Caver • Separated DC Bias Port • Low Insertion Loss, ≤4dB Typ. • Applications – NRZ, DPSK, BPSK, OBD Optical […]

20Gbps Intensity Modulator, Fujitsu FTM7920FBA

Oclaro-F10
10Gbps Intensity Modulator, OCLARO F10 Series Oclaro intensity modulators are based on the Mach-Zehnder Interferometer architecture. They are manufactured using the highly reliable Titanium indiffusion technology in x-cut, ypropagating Lithium Niobate substrates. This 10 Gb/s – 12.5 Gb/s Modulator is designed for high bit rate advanced Metro to Long Haul […]

10Gbps Intensity Modulator, OCLARO F10 Series

ftm7927-overviewr
10Gbps Intensity Modulator, Fujitsu FTM7927FBA, Lithium Niobate Fiber Modulator 10Gbps Intensity Modulator with the Features of Low Drive Voltage, RF VπVoltage 5V@16GHz, Typ. Low Insertion Loss, ≤6dB Typ. Mach-Zehnder Modulator for RZ Pulse Caver Separated DC Bias Port, Integrated Monitor Photodiode for Auto Bias Control Compact Size, 65×11.4×4.9mm, PMF at Input […]

10Gbps Intensity Modulator, Fujitsu FTM7927FBA, Lithium Niobate Fiber Modulator

ftm7928-new
10Gbps Intensity Modulator, Fujitsu FTM7928FB, Ultra-low Vπ＜3V@12.5Gbps 12Gbps Intensity Modulator with the Features of Low driving voltage: <3Vpi (Chirp±0.7) Low insertion loss, built-in a monitor PD for auto bias control Stable operation in long term for low DC drift Applications: Optical transponder module DWDM optical transmission equipment (2.5Gbps,10Gbps) Measurement equipment […]

10Gbps Intensity Modulator, Fujitsu FTM7928FB, Ultra-low Vπ＜3V@12.5Gbps

Lucent 2623NA - overview
Features Ti-diffusion process Single-drive technology C- and L-band models Slim, hermetic package Bandwidths up to 10 GHz Operational over a temperature range of 0 °C to 70 °C 43 W design for minimal electrical reflections Angled interfaces for minimal optical reflections Integrated optical attenuator available on 10 Gbits/s modulator (2623NA) […]

10Gbps Intensity Modulator, Lucent or Agere 2623NA

t-mxh1-5-10pd-adc-overview2
10Gbps Intensity Modulator with the Features of Low Drive Voltage, RF VπVoltage 5.5V@10GHz, Typ. C and L-Band Operation Enhanced E/O Bandwidth for up to 12.5 Gb/s Modulation Speed Low Insertion Loss, 5.0dB Typ. High Extinction Ratio, 30dB Typ. Integrated Monitor Photodiode Available with Zero Chirp

10Gbps Intensity Modulator, Sumitomo T.MXH1.5-10PD-ADC

t-dkh1-5-40pd-adc
40Gbps Intensity Modulator with the Features of Low Drive Voltage, RF VπVoltage 4V@20GHz, Typ. at Single Drive Mode. C and L-Band Operation. Enhanced E/O Bandwidth for up to 40 Gb/s Modulation Speed Low Insertion Loss, 9.0dB Typ. Integrated Monitor Photodiode. Supports Both Dual-drive and Single-drive.

40Gbps Intensity Modulator, Sumitomo T.DKH1.5-40PD-ADC

t-dkh1-5-10pd-adc
10Gbps Intensity Modulator with the Features of Low Drive Voltage, RF VπVoltage 6V@10GHz, Typ. at Single Drive Mode. C and L-Band Operation. Enhanced E/O Bandwidth for up to 12.5 Gb/s Modulation Speed Low Insertion Loss, 5.5dB Typ. Integrated Monitor Photodiode. Supports Both Dual-drive and Single-drive.

10Gbps Intensity Modulator, Sumitomo T.DKH1.5-10PD-ADC

Z-X5-Overview
  10Gbps LN Intensity Modulator, JDSU X5, 40dB Extra-High Extinction Ratio JDSU X5 and Z5 single drive 10 Gb/s modulators with integrated photodiode are ideally suited for use in long reach (LR)/ very long reach (VR) Metro applications as well as in long haul (LH) transmission. The X5 is a […]

10Gbps LN Intensity Modulator, JDSU X5, 50dB Extra-High Extinction Ratio
